Darupsun
7" Display AHD 1080P Wireless Rear View Backup Camera Kit for Truck Trailer
Description:
Monitor parameter
•Screen size: 7 inches
•Supports both NTSC and PAL video systems
•Support up for 4 cameras
•Display effect can be changed for each individual camera
•Multiple Viewing Options - Single/Split Screen/Quad
•Grid lines (can be switched on/off)
•Operating frequency：2400-2483.5MHZ
•Transmitted Power:18db
•Resolution: 1024（H）×600（V）
•Contrast: 500:1
•Brightness: 500cd/m2
•Response Time(ms): 25
•Power Supply: DC12-36V
•Power consumption: <500mA
•Operating temperature: -20°C ~ 70°C
•Storage temperature: -30°C ~ 80°C
•The recorder can support 8GB-128GB SD card
Camera parameter
•Image Sensor：1/3 inch infrared HD
•Picture Elements：250,000 pixels
•View Angle: 127°[H] 170°[D]
• Effective Pixel: 1280(H) x 720(V) pixels
•TV System: PAL/NTSC
•Waterproof Rating：IP68
•Minimum illumination: 0.5lux
•Power Supply: DC12V-36V
•Operating frequency：2400-2483.5MHZ
•Operating Temperature -20°C ~ +70°C
•Storage Temperature -30°C ~ +80°C
7" Monitor with 1CH Rear View Camera Package Included:
1 x Monitor
1 x Camera
2 x TV Antenna
4 x Installation Kits
2 x Power Cable
1 x Car Charger
1 x Sunshade
1 x U -Shaped Fixed Bracket
7" Monitor with 2CH Rear View Camera Package Included:
1 x Monitor
2 x Camera
3 x TV Antenna
4 x Installation Kits
3 x Power Cable
1 x Car Charger
1 x Sunshade
1 x U -Shaped Fixed Bracket
7" Monitor with 3CH Rear View Camera Package Included:
1 x Monitor
3 x Camera
4 x TV Antenna
4 x Installation Kits
4 x Power Cable
1 x Car Charger
1 x Sunshade
1 x U -Shaped Fixed Bracket
7" Monitor with 4CH Rear View Camera Package Included:
1 x Monitor
4 x Camera
5 x TV Antenna
4 x Installation Kits
5 x Power Cable
1 x Car Charger
1 x Sunshade
1 x U -Shaped Fixed Bracket
Customer Reviews
This camera and monitor are very well made. The installation was very easy as you simply need a 12 volt power wire and a good ground to operate the camera and the same for the monitor. The picture quality is very, very good. The signal strength is great and in fact, I tested how far I could put the camera away from the monitor and still have a crisp, clear picture and the distance was more than 100 feet.
For the money you cannot beat this item. I have one on both of my vehicles and it works phenomenally. Knocked a star in easy install because the there is a large plastic cylinder on the cord that I’m sure serves some purpose but makes it hard to run through tight spaces.
Just installed this yesterday on my truck. Nice daytime and nighttime images. I replaced an older camera that failed. Since I already had my truck previously wired I connected this camera to my existing wiring. Easy easy connection but you have to be careful because video and power connections/wires are very thin. I highly recommend this camera...it's a great value and it does the job! The camera is wired into my Pioneer stereo used as a monitor. My camera came with all the wiring to connect your existing monitor... Highly recommended.
My older truck never had a back-up camera so I purchased this one for it. The camera was easy to install and the large screen is clear and the image sharp. Very pleased so far!
Easy to install, works great and customer service is there when you need them
